Model Number
|
GAL150W
|
|
SYSTEM
|
|
Processor
|
Intel® Alder Lake-N95, N97, N100 Processor
Intel® Core™ i3-1115G4, i5-1135G7 Processor
Intel® Core™ i3-1215U, i5-1235U Processor
|
|
Memory
|
1*DDR4/DDR5 8GB/16GB/32GB
|
|
Storage
|
M.2 128GB/256GB/512GB
|
|
OS
|
Windows 11
|
|
DISPLAY
|
|
Type
|
15” LED Backlight LCD, 1024*768 Pixels
|
|
Resolution
|
1024*768
|
|
Aspect Ratio
|
4:3
|
|
Brightness
|
Typ.350 cd/m2
|
|
Touchscreen
|
Projective Capacitive Touch Screen
|
|
INTERFACE
|
|
Display
|
1*HDMI
|
|
USB
|
2*USB3.0 Type A, 1*USB3.0 Type C, 4*USB2.0
|
|
LAN
|
1*RJ45 Gigabit Ethernet
|
|
COM
|
2*RJ50(RS232)
|
|
Cash Drawer
|
1*RJ11
|
|
Audio
|
1*Line-Out + Mic-In 2-in-1 Φ3.5mm Jack
|
|
Power DC-IN
|
1*Mini-DIN 3P Jack
|
|
POWER
|
|
Power Supply
|
AC-In 100~240V / DC-Out 24V 2.5A/3.75A
|
|
PHYSICAL&ENVIRONMENTAL
|
|
Operating Temperature
|
Operating 0~50°
|
|
Operating Temperature
|
Storage-20°~60°
|
|
Color
|
Matte Black/Slate
|
|
OPTIONS & PERIPHERALS
|
|
2nd Display
|
10.1/11.6/15/15.6 Inch LED Backlight LCD, Capacitive Touch Optional
|
|
Card Reader
|
MSR Card Reader, Fingerprint, and iButton Modules Optional
|
|
Wifi & Bluetooth
|
Wi-Fi5, Wi-Fi6 2.4GHz/5GHz & Bluetooth Optional
|
|
Speaker
|
1*2W Speaker
|
