ZAF215K-A (Supermarket Version)

Gallery Features Specs Video Accessory
ZAF215K-A (Supermarket Version)

Function introduction

21.5" Self-service Kiosk (Supermarket version)
Product consulting Data download
Share：
  • ZAF215K-A
  • ZAF215K-A
  • ZAF215K-A
  • ZAF215K-A
Features

21.5" Self-service Kiosk

ZAFIRO SUPERMARKET VERSION


21.5" FHD Touch Display


21.5-inch FHD bezel-free screen with superior visual experience and smooth user-interaction.


Color LED Indicator

Multicolor lights provide real-time visual alerts for instant equipment monitoring.


Modular Design

Supports optional modules including payment terminal, MSR, NFC and camera to fit varied commercial scenarios.


High-Speed Printer

Ensures rapid receipt printing with eortless paper roll replacement to minimize downtime.


2D Barcode Scanner

High-performance scanning instantly reads product QR codes to streamline checkout.

Specs
  • OS

    Android 11

  • CPU

    RK3568/RK3576

  • Memory

    4GB ROM
    + 32GB RAM

  • Main Display

    21.5 Inch TFT LED Backlight LCD

  • Scanner

    2D Barcode Scanner

  • Printer

    3" Printer W/Auto Cutter, 200 mm/sec (Max.)

  • NFC

    NFC Option

  • Camera

    2 MP Wide Angle Camera (Option)

Model Number ZAF215K-A(Supermarket Version)
SYSTEM
Processor RK3568 Quad-Core Cortex-A55 up to 2.0GHz
RK3576 Quad-core Cortex-A72 + Quad-core Cortex-A53 up to 2.2GHz
Memory 4GB DDR4
Storage 32GB EMMC
OS Android 11
DISPLAY
Type 21.5 Inch TFT LED Backlight LCD
Resolution 1920*1080
Aspect Ratio 16:9
Brightness 300cd/m2
Touchscreen Projective Capacitive Touch Screen
INTERFACE
Display 1*HDMI
Standard USB Port 2*Internal USB, 2*External USB
LAN 1*Gigabit Ethernet, RJ45
Audio 2*Internal 3W Speaker
Power DC-IN Input AC 100~240V/50~60hz
STANDARD COMPONENTS
Scanner 2D Barcode Scanner
Printer 3" Printer W/Auto Cutter, 200 mm/sec (Max.)
Status Indicator Color LED Indicator
PHYSICAL&ENVIRONMENTAL
Operating Temperature Operating 0~60°
Operating Temperature Storage -35°~75°
Cooling Fanless or with CPU Fan
Dimensions(W×H×D) Wall Mounting: 923.5*422*115(mm)
Floor-standing: 1734*550*450(mm)
Net Weight Countertop Stand: 24.84kg
Floor-standing: 45.42kg
Color Black/Silver
OPTIONS & PERIPHERALS
Wifi IEEE 802.11 a/b/g/n/ac, 2.4Ghz
Bluetooth Bluetooth 5.0(Option)
MSR Comply with ISO 7811, Support 1&2&3 Track (Option)
NFC MIFARE, FeliCa, IS0/IEC 14443A/B
ISO/IEC 18092,ECMA 340 NFCIP-1 Peer-to-Peer (Option)
Camera 2 MP Wide Angle Camera (Option)
4G/LTE Communication Support Selected Bands & Countries With Full SIM Slot (Mini-pcl e Module) By Request
Payment Termimal Bracket Adjustable Bracket (Option)
