MEG215AD

MEG215AD

Function introduction

The Megaera is the new all-in-one POS terminal. It packs innovativeness and functionality in compact design with stylish
look, which is ideal for retail businesses where space is at premium.
Share:
  • MEG215AD
  • MEG215AD
  • MEG215AD
Features

21.5 inch Self-Ordering Kiosks


Impressive Visual Experience & Multipurpose

21.5 inch FHD wide viewing angle display, Megaera Series adapts to changing business needs as well as consumers’ demands. It serves as product display & advertising, ordering & payment, click & collect, ticketing & e-reservations and whatever business scenarios you wish.


More accessories options

Equipped with a wide array of choices of peripherals including 2D scanner, camera and a bracket for EMV payment devices and offering two choices of counter-top or floor-standing. The Megaera Series is able to fulfill with all kinds of self-service tasks.

Specs
  • OS

    Android 11

  • CPU

    RK3568 / RK3399

  • Memory

    2GB ROM + 16GB RAM

  • Main Display

    21.5 Inch TFT LED Backlight LCD

  • Scanner

    2D Barcode Scanner

  • Printer

    Standard 80mm (58mm Option)

  • Wifi

    Support

  • Bluetooth

    Support

Model Number MEG215AF
SYSTEM
Processor RK3568 ARM Cortex-A55 Quad-Core, 2.0GHz
RK3399 ARM Cortex-A72 Dual-core+Cortex-A53 Quad-core
Memory Standard 2GB, up to 4GB
Storage Standard 16GB, up to 8/32/64GB
OS Android 11
DISPLAY
Type 21.5-inch TFT LED Backlight LCD
Resolution 1080*1920
Aspect Ratio 9:16
Brightness 250 nits
Touchscreen Projective Capacitive Touch Screen
INTERFACE
USB 1* External USB2.0
LAN 1*Gigabit Ehernet, RJ45
Power DC-IN Input AC 100~240V/50~60hz, Output DC12V/5A
PHYSICAL&ENVIRONMENTAL
Operating Temperature Operating 0~60°
Operating Temperature Storage -35°~75°
Cooling Fanless
Dimensions(W×H×D) Mainframe Section: 31.4x35.6x72.5(cm) ;
Column Section: 20x20x88(cm);
Overall Size: 156.22x45x55(cm)
Packing Dimensions(W×H×D) Mainframe Section: 31x36x85.5(cm) ;
Column Section: 26x96x26.5(cm)
Net Weight Mainframe Section: 14.3kg ;
Column Section: 9.88kg
Packing Weight Mainframe Section: 16.18kg ;
Column Section: 11.74kg
Color Black/Silver
OPTIONS & PERIPHERALS
Wifi Built-in Wifi, Support Dual-band Wifi, Single Antenna
Bluetooth Bluetooth 4.0 Protocol
Printer Standard 80mm Printer, 58mm Printer Option
Scanner 2d Scanner For Payment or 2d Scanner for Goods Option
Payment Terminal Reserved Space for Payment Terminal(Size Customizable)
